6. RADAR
6-27
• FAR-2xx7 series: C-types only with software version 04.08, or later.
• FAR-2xx8 series: NavNet TZtouch3 with software version 1.06 or later and set as
Master. Catch data import/export is restricted to TZX format.
Note 1: Polygon acquisition zones must be also be disabled at the radar.
Note 2: For FAR-15xx series users, the Echo Average function is only applied to im-
ages from EAV1 when displayed on your TZtouch2 unit.
When connection with the radar is established, some radar functions are available to
use from the TZTouch2. See the following table for details.
Radar function
Available from the
TZTouch2?
Remarks
Split-screen display Not available
Display AIS target data Available
ARPA automatic acquisition Not Available
ARPA manual acquisition and re-
moval
Available Up to 100 targets.
AUTO RAIN Not available
AUTO SEA Available ON/OFF operation only, set-
ting adjustment must be
done at the radar.
Automatic gain adjustment Not available
Manual rain/snow clutter removal Available
Manual gain adjustment Available
Toggle transmit and standby
modes
Available
Interference Rejector Available
Tuning, antenna sped and other
post-installation adjustments
Not available
Radar source selection, display of
echoes
Available
Selection of range unit Not available Fixed at [NM].
Changing the range Available Following ranges only:
0.125, 0.25, 0.5, 0.75, 1, 1.5,
2, 3, 4, 6, 8, 12, 16, 24, 32,
48, 96 (nm).
Watchman feature Not available
ACE GAIN Available* *: This function is only avail-
able for the FAR-15xx series
and requires ACE GAIN to
be enabled from the radar.
