Fusion MS-IP700 User Manual

36
ETHERNET CONNECTION
ForconnectiontoaDHCPEthernetRouterforcommunicationwithFUSION-Link
capable devices.
SiriusXM SATELLITE RADIO (For use in USA only)
ConnecttoSiriusXMConnectVehicleTuner(notincluded)
ZONE CONNECTIONS
Zone1   White=SpeakerLeftPositive
   White/Black=SpeakerLeftNegative
   Grey=SpeakerRightPositive
   Grey/Black=SpeakerRightNegative
Zone2   Green=SpeakerLeftPositive
   Green/Black=SpeakerLeftNegative
   Purple=SpeakerRightPositive
   Purple/Black=SpeakerRightNegative
Note:Speakerconnection(2OhmStereominimum).2pairsof4Ohmspeakersper
channel can be connected in parallel to achieve 2 Ohm configuration
Zone1LineOut(Redwire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
Zone2LineOut(Whitewire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
Zone3LineOut(Greywire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
Zone4LineOut(Blackwire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
