SETTING UP THE 700 SERIES
ZONES
Zone1and2arepoweredbytheonboardClass-Damplier.External
ampliersarerequiredtoutilizethe4lineoutputsand4subwooferoutputs.
You can pre-set the balance, volume limit, sub-woofer level and name for each
ofthefourZonesavailableonthe700Series.Ifrequired,youcanalso:
• EnableordisableZones2,3and4(Zone1isalwaysenabled).
• Enableordisablevolumecontrol(Zones3and4only).
• LinkZones1and2.
• DisabletheinternalampliersforZones1and2.Forexample,if
external amplifiers are used for Zones 1 and 2 the internal amplifiers
can be disabled to reduce power consumption.
Selecting and setting up a zone
To select a Zone and modify its settings:
1. Press the Menu key.
2. TurnandthenpresstheEncodertoselectSettings > Zone.
3. TurnandthenpresstheEncodertoselecttheZoneyouwishtoworkwith.
4. Use any of the following instructions to update settings for the selected Zone.
Enabled
Zones2–4canbedisabledifrequired.Thisisuseful,forexample,ifonlytwo
Zones have been set up, as disabled Zones are not displayed in any screens
when setting levels.
To enable or disable the selected Zone:
a. Select the Enabled menu item.
b. PresstheEncodertoenable()ordisable()theselectedZone.
c. Press any key to exit
To disable or enable the internal amplifiers for Zones 1 and 2:
a. Select the Internal amplifier on menu item from the Zone menu.
b.PresstheEncodertodisable()orenable()theampliers
c. Press any key to exit
