Fusion MS-IP700 - Clock Display Mode

48
Recommended settings are listed below:
Note: When using the headphone output of a portable device, it may be
necessary to adjust the device’s own volume control for best
audio quality.
CLOCK SETTING
The 700 Series unit has a built-in clock that can display the time in 12-hour
or 24-hour mode.
To set the clock:
1. Press the Menu key.
2. TurnandthenpresstheEncodertoselectSettings > Clock > Set clock.
The Set Clock screen is displayed.
3. TurntheEncodertochangethehoursetting.
4. Ifrequired,presstheEncodertomovetotheminuteseld.Turnthe
Encodertochangetheminutessetting.
AUX Device AUX gain
setting (dB)
Portable media player with headphone output -9dB to -6dB
CD/DVD player with line output -6dB
Portable media player with line output 0dB
Game console with line output 0dB
Older audio/visual equipment with line output (for example:
VHS or cassette deck)
6dB to 9dB
