Fusion MS-IP700i

32
ETHERNET CONNECTION TO PARTNERED MFD
ForconnectiontoaDHCPEthernetRouterorFUSION-Linkpartnered
Multi Function Displays.
SiriusXM SATELLITE RADIO
(A) ConnecttoSiriusXMConnectVehicleTuner(notincluded)(ForuseinUSAonly)
(B) ConnecttheMS-BT200module(notincluded)
ZONE CONNECTIONS
Zone1   White=SpeakerLeftPositive
   White/Black=SpeakerLeftNegative
   Grey=SpeakerRightPositive
   Grey/Black=SpeakerRightNegative
Zone2   Green=SpeakerLeftPositive
   Green/Black=SpeakerLeftNegative
   Purple=SpeakerRightPositive
   Purple/Black=SpeakerRightNegative
Note:Speakerconnection(2OhmStereominimum).2pairsof4Ohmspeakersper
channel can be connected in parallel to achieve 2 Ohm configuration
Zone1LineOut(Redwire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
Zone2LineOut(Whitewire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
Zone3LineOut(Greywire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
Zone4LineOut(Blackwire) Lowleveloutput
    (Forconnectiontoexternalamplier)
    WhiteRCA=LeftOutput
    RedRCA=RightOutput
    BrownRCA=SubwooferOutput
