FUTABA FP-7UAF User Manual

• TABLE OF CONTENTS
SET CONTENTS ........................................... 2
BEFORE USING .......................................... 3-5
DISPLAY FUNCTIONS
NORMAL DISPLAY
MODE .............................. 6
ERROR DISPLAY MODE ................................ 7
EDIT DISPLAY MODE .................................. 7
FUNCTIONS AND DATA SETTING
ADJUSTABLE TRAVEL VOLUME ........................ 8
DUAL RATE .......................................... 8
EXPONENTIAL........................................ 9
REVERSE ............................................ 9
FAIL SAFE ........................................... 10
PROGRAMMABLE MIXING 1 ............................ 11
PROGRAMMABLE MIXING 2 ............................ 12
ELEVATOR -> FLAP MIXING ............................ 13
FLAP -> ELEVATOR MIXING ............................ 14
SNAP-ROLL .......................................... 15
AILERON DIFFERENTIAL .............................. 16
FLAPERON ........................................... 17
FLAP TRIM ........................................... 18
SUB TRIM.............................................18
COMBINATION SWITCH ................................ 18
MODULATION ........................................ 19
OTHER FUNCTIONS .................................... 19-20
USING THE ACCESSORIES ............................... 20-21
NOMENCLATURE (DOUBLE FOLDOUT) ...................... 22
SERVO EXPLODED VIEW ................................... 23
ABBREVIATIONS
ATV ADJUSTABLE TRAVEL FLPR FLAPERON
VOLUME FLTR FLAP TRIM
D/R DUAL RATE STRM SUB TRIM
EXP EXPONENTIAL COMB COMBINATION SWITCH
REV REVERSE MOD MODULATION
F/S FAILSAFE AUX AUXILIARY
PMX PROGRAMMABLE MIXING PCM PULSE CODE MODULATI
2->6 ELEVATOR^ FLAP MIXING PPM PULSE POSITION
6->2 FLAP -> ELEVATOR MIXING MODULATION
SNP SNAP-ROLL B.F/S BATTERY FAIL SAFE
DIFF AILERON DIFFERENTIAL
—1 —

FUTABA FP-7UAF Specifications

General

Brand	FUTABA
Model	FP-7UAF
Category	Remote Control
Language	English
