FUTABA FX-36 - Page 111

111
＜ Linkagemenu ＞
ŏ Select [Current] in the Telemetry screen and
access the setup screen shown below.
ŏReturn to
Linkage menu
'ULYH
%DWWHU\
6%6&
WR5HFHLYHU
0RWRU
(6&
*Currentsensormustbeinstalledinthe
aircraft.
◆ Alarmsetting
Max.andmin.values
sincethepower
wasturnedONwill
display.
Setsthecurrenton
whichthealarm
operates.
Alarmischosenfrom
Buzzer,Voice,and
Inhibit.
AllowsSpeechtobe
turnedONorOFF.
Tappingthiswilltakeyouto
thesettingsscreenforthe
currentalarm
Tappingthiswilltakeyouto
thesettingsscreenforthe
voltagealarm
Tappingthiswilltakeyouto
thesettingsscreenforthe
consumptioncapacityalarm
↑Anupwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesabove
yoursetvalue.
↓Adownwardarrow
indicatesthealarm
willsoundwhenthe
currentreachesbelow
yoursetvalue.
Type1
Type2
Type3
"Vibrator"type
Ifthefollowingtypesareselected,thetransmitter
willvibrateduringthewarning.
Telemetry:Currentsensor[Current]
The SBS-01C has the capability of measuring
current, voltage and capacity (consumption) from
drive battery all at the same time.
Theconsumptioncapacityisindicated.
Itisn'tthepresentbatterycapacity.
