FUTABA FX-36 - T T1 T

79
＜ Linkagemenu ＞
Trimsetting(T1-T6)
Digital trim settings
This function adjusts the digital trim's control
step amount and operation mode (T1-T6).
Control step amount setting
1. The [Step] item tap the screen to the data
input mode.
Set the control step amount by tapping the
"
▲▲
" "
▲
"

"
▼▼
" "
▼
" button.
Initial value: 4
Adjustment range: 1~200
(When the value is tapped, the control step
amount is reset to the initial value.)
*When the value is made large, the change per step becomes
larger.
Separate/combination mode selection
[Comb.]: Combination mode. The trim data
are reÁected at all the Áight conditions.
[Separ.]: Separate mode. Trim adjustment for
each Áight condition.
ŏ Select [Trim setting] at the linkage menu and call
the setup screen shown below.
When the flight conditions are set, the trim
operation can be coupled with among all the
conditions which combination mode is selected.
ŏReturn to Linkage
menu
