80
＜ Linkagemenu ＞
ŏ Tap the [Throttle cut] button in the Linkage menu to
call the setup screen shown below.
Throttlecut
Stops the engine safely and easily.
Throttle cut provides an easy way to stop the
engine, by Àipping a switch with the throttle stick at
idle. The action is not functional at high throttle to
avoid accidental dead sticks. The switch’s location
and direction must be chosen, as it defaults to "
−
−"
.
Throttle cut setting procedure
1. Tap the "INH" button.
2. Throttle cut function switch setting:
Tap the "--" button to call the Hardware
select! screen, and then select the switch
and its ON direction.
(For a detailed description of the selection
method, see [Switch selection method] at
the back of this manual.)
3. Throttle cut position setting:
Tap the cut position button. Value input
buttons appear on the screen.
8se these buttons to adjust the cut
position rate.
ŏInitial value: 17
ŏAdjustment range:
（
LOW
）
0~50
（
Middle
）
*With throttle stick at idle, adjust the rate until the engine
consistently shuts off.
To exit the setting, tap the [Throttle cut]
button.
Theyellowlineisthe
cutposition.When
thecutswitchisON,
thethrottlewillmove
tothisposition.
Tappingthiswillpullupthe
hardwareselectionscreen.
Selectthethrottlecutswitch
andON-OFFdirection.
Thisindicatesthethrottlestick'scurrent
position.Throttlecutwillonlyfunction
whenthethrottlestickismorethan1/3rd
intotheslowthrottlerange.
Tappingthiswillchange
INHtoeitherOFForON
andactivated.
ŏReturn to
Linkage menu
Thisisthethrottlecut
position.Tappingthis
willdisplayvalueinput
buttonson-screen.Set
theenginestopposition.
