FUTABA FX-36 - U U

58
＜ Systemmenu ＞
Stick mode selection and -1--4 sticks calibration
Thestickissetat
neutral
Fullrightand
fullbottom
Fullleftand
fulltop
H/Wsetting
Usually, this H/W setting is unnecessary.
Please perform this calibration only if a change at
the center of a stick should arise after prolonged use.
2. Choose the stick to calibrate right and left.
3. The stick is set at neutral and the [Set neutral]
button is tapped.
How to Calibrate
1. Tap the "Calibration" button.
*Please do not press the stick too ¿rmly in any direction when
doing the calibration.
*Check after calibration to make sure that neutral is 0%, the
bottom right side is +100%, and the top left side is -100%.
ŏ Tap the [Calibration] button in the System
menu to call the setup screen shown below.
ŏReturn to
System menu
4. The stick is held at full right and full bottom
(diagonal). The [Set endpoint] button is
tapped.
5. The stick is held at full left and full top
(diagonal). The [Set endpoint] button is
tapped.
Tapped
Tapped
Tapped
Stick mode
Mode 1-4 can be chosen.
But, it isn't change until data is reset.
To change the mode the stick ratchet
must be changed. Request that this
be done by Futaba Service. (Charged
modi¿cation)
MODE1 MODE2
MODE3 MODE4
