＜ BeforeUse ＞
ŦƒƑƗƈƑƗƖŃƄƑƇŃŷƈƆƋƑƌƆƄƏŃŶƓƈƆƌƲƆƄƗƌƒƑƖ
Speci¿cations and ratings are subject to change without notice.
YourFX-36includesthefollowingcomponents:
•FX-36transmitter•R7008SBReceiver
•6.0VNiMHbattery2500mAhandcharginglead
•Switchharness•2stickextensionsM4foruseintray
•Aluminiumcase•Minidriver•Swingarmstopperandsetscrew
*Thesetcontentsdependonthetypeofset.
ŷƕƄƑƖƐƌƗƗƈƕŃũŻŐŖřŃ
(2-stick,18-channel,FASSTest-2.4GHzsystem)
Transmittingfrequency:2.4GHzband
System:FASSTest18CH,FASSTest12CH,FASSTMULT,FASST7CH,T-FHSS,S-FHSS,switchable
Powerrequirement:6.0V-7.4Vbattery
Frequencyband:2.4GHz
RFpoweroutput:100mWEIRP
ŵƈƆƈƌƙƈƕŃŵŚœœśŶť
(FASSTest-2.4GHzsystem,DualAntennaDiversity,S.BUS/S.BUS2system)
Powerrequirement:3.7V-7.4VbatteryorregulatedoutputfromESC,etc.(*1)
Size:0.98x1.86x0.56in.(24.9x47.3x14.3mm)
Weight:0.38oz.(10.9g)
Frequencyband:2.4GHz
RFpoweroutput:25mWEIRP
(*1)WhenusingESCsmakesurethattheregulatedoutputcapacitymeetsyourusageapplication.
Note: The battery in the FX-36 transmitter does not arrive already attached
to the battery connector. Please connect the battery connector before use.
ŶƈƏƉŃƑƈƘƗƕƄƏŃƖƗƌƆƎ
Throttlestickwarning
Thethrottlestick
returnsneutrallybya
spring.
Ratchettype
（Generaltransmitter）
Thethrottlestickdoesn't
returnneutrally.
Youcannotusetheself-neutralthrottlestickforR/Cairplanes,helicopters,andcertainmulti-copters.
Allowingtheengine/motortoreachmiddlespeedviaautomaticthrottlestickreturnisverydangerous.
IfusingtheFX-36forR/Cairplanesandhelicopters,youmustchangethethrottlesticktotheratchettype.
Selfneutraltype
（FX-36）
WARNING
