FUTABA FX-36 - Page 146

146
＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
Whenusingthis
function,Tap[INH].
(ONisdisplayed.)
TheON/OFFswitchof
airbrakeischosen.
Thevalueinsidethe
parenthesesshowsthe
currentrudderposition.
Manual/Automode
selection
Manual:Switchesthe
functionON/OFFby
switch
Auto:Airbrakefunction
callcanbelinkedtoa
stick,etc.Astickswitch,
etc.separatefromthe
functionON/OFFswitch
isset.
Offset：Theoffset
rateofailerons,flaps,
andelevatorscanbe
adjusted.Taptothe
correspondingsetting
item.Adjusttherate.
Finetuning：Whenafine
tuningVRissetonthe
nextpage,theailerons',
flaps',andelevators'trim
ratescanbeadjusted.
Taptothecorresponding
settingitem.Adjustthe
rate.
Conditiondelay
settingandcutswitch
setting.
Finetuningsetting
Aileron1
Aileron2
Elevator
Airbrake
This function is used when an air brake is
necessary when landing or diving, etc.
The preset elevators and flaps (camber flap,
brake flap) offset amount can be activated by a
switch.
The offset amount of the aileron, elevator, and
flap servos can be adjusted as needed. Also the
speed of the aileron, elevator, and Àap servos can
be adjusted. (In side/Out side) A delay can be set
for each condition, and a Cut switch which will
turn OFF the delay can be chosen. Trim amounts
can be fine-tuned by setting a VR. You can also
set the Auto Mode, which will link Airbrake to a
stick, switch, or dial. A separate stick switch or
dial can also be set as the ON/OFF switch.
ŏ Select [Air brake] at the model menu and call the
setup screen shown below.
*Thedisplayscreenisanexample.Theactual
screendependsontheModelType.
Inspeed
Outspeed
（First）0〜27（Slowly）
Tonextpage
ŏReturn to Model menu
