179
＜ Data ＞
◆ AreaGreen：ON
◆ AreaRed：OFF
◆ AreaYellow：Hysteresis(Deadband)
[Settingmethod]
[Settingmethod] → BoxType
1. Move the stick, etc. to
the point you want to shift
and touch the [ON/OFF]
button. The boundary
points change.
1. Move the stick to the point
you want to shift upper side.
3. Move the stick to the point
you want to shift lower side.
Currentstickposition
ReverseofON/
OFFdirection
2. Touch the [Upper] button.
The boundary points
change.
4. Touch the [Lower] button.
The boundary points
change.
● Symmetry
● Symmetry
When shifting the ON/OFF point
The ON/OFF and hysteresis (dead band) boundary point (there
are 2 points: top and bottom) position can be shifted. ON/OFF is
possible at a free position.
When Upper
(Lower) is set, at the
same time, Lower
(Upper) is also set.
When Upper (Lower) is
set, at the same time,
Lower (Upper) is also set.
Hysteresis
：
Hysteresis (dead band) can be set to ON and OFF
[Settingmethod] → LinearType
1. Move the stick to the off
point you want to shift and
touch the [OFF] button. The
off points change.
2. Move the stick to the on
point you want to shift and
touch the [ON] button. The
on points change.
