46
SWH. BASIC screen 1/5
From 5/5 From the "Pit.Low" of
SWH. BASIC screen 5/5
Go to 2/5 from any cursor position
: :
:
(1) Setup style
3D mode contains a proven set of parameters which are good for not
only 3D but also F3C flying. F3C Mode and L.SCALE (Large scale
model) Mode are for unique or special tuning types only.
*When the style is changed, setting of AIL/ELE/RUD is re-initialized and
defaults are changed.
Move the cursor to "Setup style" by pressing the [
/+] or [ /-] key and
press the [Enter] key to enter the setting mode. Use the [
/+] or [ /-] key
to set the style. When "EXECUTE: Enter (1
sec)" is displayed. Press the
[Enter] key for about 1
second to changes the selected style. The pro-
gram will also exit the setting mode accordingly.
L.SCALE: Initial parameter mode corresponding to a large machine with a total
length of 2.5
m or more.
(2) Gyro Set Dir: Mounting direction
Set the roll axis, pitch axis, yaw axis according to the mounting direction of
CGY. Set mounting direction with reference to page 18-19. Move the cur-
sor to "Gyro Set Dir" by pressing the [
/+] or [ /-] key and press the [Enter]
key to enter the mounting direction. Then select the mounting direction #
with the [
/+] or [ /-] key. When you finish setting, press [Enter] key to exit
setting mode. When the LED on the Gx side finishes blinking, please turn
the power off and on again to confirm that it is working properly.
Setting: 1 ~ 6 Initial setting: 1
WARNING
If you do not turn the power back on after changing "Gyro Set Dir", the gyro
will not operate properly, there is a risk of crashing.
To Next Page
