65
WARNING
When using the CGY for the first time, or when
making changes in the throw of a servo and its link
-
age, always perform the limit setting operation.
How to set the servo limit point:
Set the transmitter's throttle stick to the idle position. Select [Lim. Set Id]
with the [
/+] or [ /-] key and press the [Enter] key to enter the setting
mode. "EXECUTE: Enter (1
sec)" is displayed. Press the [Enter] key for
about 1
second. The cursor will move to "Lim. Set IHi". Set the stick to the
full high position and set the same as "Lim. Set Id". If the setting data is not
normal (servo operation amount is 50% or less), "Err" is displayed. In this
case, check the transmitter setting and repeat this procedure once again.
GOV. BASIC screen 4/6
From 3/6
Go to 5/6 from any
cursor position
(10) Limit Test: Check the set limit point
Check the set limit point. Use the [ /+] or [ /-] key to move the cursor to
"LIMIT Test Idle" and press the [Enter] key to move the servo to the idle
point "END" will be displayed on screen. Similarly on the high side, use
the [
/+] or [ /-] key to select the cursor "LIMIT Test HIGH" and test it with
the [Enter] key.
GOV. BASIC screen 3/6
From 2/6
Go to 4/6 from any
cursor position
(9) Lim. set: Servo limit point setting
Servo limit point setting defines the overall travel
range for the throttle servo. It is fundamental for
governor operation and must be set prior to other
functions. Servo limits must also be reset when the
throttle linkage or trim are changed. Refer to the next
page for setting procedures and adjustments.
To Next Page
