1. Curvesettingoperation
◆ Pointadditionmethod
◆ Pointdeletionmethod
Point curves or spline curves of up to 11/17 points
can be used. (Initial value: 11/9 points) The set points
can be freely increased, decreased, and offset.
① Openthescreenofamixingcurvewiththecurve
function.
② Tapthe[Remove]button.(Theselectedpoint
becomesanoutlinedpoint □ )
③ Use
themovebetweenpointsbutton[ ←]or
[ → ].
*Thepointisdeleted.
② Tapthe"Position"button.
③ Tapthe" ▼ ▼ "" ▼ "" ▲ "" ▲ ▲ "buttonand
selecttheposition(mark□ )youwanttoadd.
① Usethemovebetweenpointsbutton[
←]or[ →]
andselectthepoint.(Thered
point ■ istheselectedpoint.)
④ When
the"Add"istapped,thepointisadded.
（□）→（■）
*Anewpointiscreated.
⑤ Press
"Rate"andusetheup/downarrowstoadjust
theratepointsupordown.
Thekindofmixingcurve
Theredpoint
（■）
moves(togreenpoint)
Movebetween
point
Aredmark
（ □ ）
movesfreely
T18SZSOFTWAREUPDATECHANGES
V1.4
This software updates or alters the functions and features noted below. The instructions and information that follow are meant as a
supplement to the original instruction manual that accompanied the T18SZ transmitter. Please refer to the original instruction manual where
applicable, but replace the steps indicated below with these instructions. Please check to ensure that the update has been installed.
1) Select the System Menu.
2) Touch the [Information] button.
3) Confirm that the information in the display indicates the version numbers as noted above.
