FUTABA T18SZ - Page 16

2. CurvesettingoperationSplinecurve
3. SBS-01Ccurrentsensorfunction
Addition of spline curve setting.
Setting method is same at spline and point.
The T18SZ has been made compatible with the
SBS-01C current sensor. The SBS-01C has the
capability of measuring current, voltage and capacity
(consumption) from the drive battery at the same time.
Splinecurve
'ULYH
%DWWHU\
6%6&
WR5HFHLYHU
0RWRU
(6&
◆ SBS-01Cisregisteredwithatransmitter.
① ConnectthesensortotheT18SZasshowninthe
figureabove.
② [Linkagemenu] → [Sensor] → [Page3/3]
isopenedfromtheT18SZ.
③Tap[Register]
④ CompleteregistrationandremoveSBS-01Cfrom
thetransmitter.
76=
SBS-01C
Thekindofmixingcurve
Point Spline
*Currentsensormustbeinstalledinthe
aircraft.
