1-7 Parameter Descriptions1-7 Parameter Descriptions
Parameter
Notation
Parameter
Description
Range
Default
Value
HSP1
LSP1
INPT
SP2
High Limit Set point 1
Low Limit Set point 1
Input Type Selection
Set point 2 Value for
Output 2
Low: HSP.L
High: HSP.H
Low: LSP.L
High: LSP.H
See Table 6-1
100.0 C
(212.0 F)
0C
(32.0 F)
90.0 C
(194.0 F)
0 : J type
thermocouple
1 : K type
thermocouple
2 : T type
thermocouple
3 : E type
thermocouple
4 : B type
thermocouple
5 : R type
thermocouple
6 : S type
thermocouple
7 : N type
thermocouple
8 : L type
thermocouple
9 : PT100
ohms DIN curve
10 : PT100
ohms JIS curve
1
(0)
16
UM L91-Rev 8
