Future Design FDC-L91 - Page 17

11 : 4~20
mA linear current
12 : 0~20
mA linear current*
13 : 0~60
mV linear voltage
14 : 0~1 V
linear voltage
15 : 0~5 V
linear voltage
16 : 1~5 V
linear voltage
17 : 0~10V
linear voltage
Parameter
Notation
Parameter
Description
Range
Default
Value
INPT
Input Type Selection
1
(0)
0
(1)
17
UNIT
RESO
Process Unit
Display Resolution
0:
Degree C unit
2:
Process unit
1:
Degree F unit
0:
No decimal point
1:
1 decimal point
2:
2 decimal point
3:
3 decimal point
1
IN.LO
Low Scale Value for
Linear Input
Low: -19999
High: IN.HI
0
*
*
*
*
*
NOTE: Inputs 11, 12, 14, 15, 16, and 17 are NOT FM Approved.
