IN.HI
SHIF
High Scale Value for
Linear Input
PV Shift ( offset )
Value
Low: IN.LO
High: 45536
Low: -200.0 C
(-360.0 F)
High: 200.0 C
(360.0 F)
100.0
0.0
Parameter
Notation
Parameter
Description
Range
Default
Value
FILT
PV Filter Time
Constant
3 : 1 second
time constant
0 : 0 second
time constant
4 : 2 seconds
time constant
5 : 5 seconds
time constant
6 : 10 seconds
time constant
7 : 20 seconds
time constant
8 : 30 seconds
time constant
9 : 60 seconds
time constant
1 : 0.2 second
time constant
2 : 0.5 second
time constant
2
OUT1
Output 1 Function
2 : High limit
control
3 : Low limit
control
2
18
4 : High/Low
limit control
