Futurecom P25 - Table 23 Typical Remote Steering Scenarios

8M083X25 R14
APX Series P25 Interface
DVRS Installation & Programming Guide – PART II
January 2019
Page 111 of 153
The following table illustrates some typical remote Steering scenarios:
Local PSU
DVRS A
Steering
BEFORE AFTER
DVRS B
Steering
BEFORE AFTER
Call Alert (Page)
to:
DVRS A
PSU on TG 1
OFF OR
LOCAL
SECONDARY
DVR CH 1
MSU TG 1
SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
SECONDARY
DVR CH 1
MSU TG 1
Call Alert (Page)
to:
DVRS A
PSU on TG 1
OFF OR
LOCAL
SECONDARY
DVR CH 1
MSU TG 1
SYSTEM
SECONDARY
DVR CH 1
MSU TG 1
LOCAL OR SYSTEM
PERM. PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
PERM. PRIMARY
DVR CH 1
MSU TG 1
Call Alert (Page)
to:
DVRS A
PSU on TG 2
OFF OR
LOCAL
SECONDARY
DVR CH 1
MSU TG 1
SYSTEM
PRIMARY
DVR CH 1
MSU TG 2
LOCAL OR SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
SECONDARY
DVR CH 1
MSU TG 1
Call Alert (Page)
to:
DVRS A
PSU on TG 2
OFF OR
LOCAL
SECONDARY
DVR CH 1
MSU TG 1
SYSTEM
SECONDARY
DVR CH 1
MSU TG 2
LOCAL OR
SYSTEM
PERM. PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
PERM. PRIMARY
DVR CH 1
MSU TG 1
Call Alert (Page)
to:
DVRS A
PSU on CONV1
OFF OR
LOCAL
SECONDARY
DVR CH 1
MSU TG 1
SYSTEM
PRIMARY
DVR CH 1
MSU CONV1
LOCAL OR
SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
SECONDARY
DVR CH 1
MSU TG 1
Call Alert
(Page) to:
DVRS A
PSU on TG1
OFF OR
LOCAL
SECONDARY
DVR CH 1
MSU CONV1
SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
LOCAL OR
SYSTEM
SECONDARY
DVR CH 1
MSU TG 1
Table 23 Typical Remote Steering Scenarios
