• Activation / Deactivation: The DVRS activates when the VIP input is asserted
and deactivates when the VIP input is de-asserted.
• Activation Only: The DVRS activates when the VIP input is asserted and does
NOT deactivate when the VIP input is de-asserted.
• Toggle: The state of the DVR is toggled every time the VIP Input is asserted. No
action is taken when the VIP Input is de-asserted. This setting is intended to be
used when a car door switch is used as the AVRA trigger (opening the door
activates the DVR but closing it does not deactivate it).
The following table provides summary of the AVRA functionality as a function of the DVR
programming:
AVRA Configuration
System Mode
Allowed
VIP Input
Current DVR
Mode
New DVR mode
Activation / Deactivation
True
Asserted
OFF
SYSTEM
Activation / Deactivation
False
Asserted
OFF
LOCAL
Activation / Deactivation
True
Asserted
LOCAL
SYSTEM
Activation / Deactivation
False
Asserted
LOCAL
LOCAL
Activation / Deactivation
True
Asserted
SYSTEM
SYSTEM
Activation / Deactivation
True/False
De-
asserted
ANY
OFF
Activation Only
True
Asserted
OFF
SYSTEM
Activation Only
False
Asserted
OFF
LOCAL
Activation Only
True
Asserted
LOCAL
SYSTEM
Activation Only
False
Asserted
LOCAL
LOCAL
Activation Only
True
Asserted
SYSTEM
SYSTEM
Activation Only
True/False
De-
asserted
ANY
NO CHANGE
Toggle
True
Asserted 1
st
OFF
SYSTEM
Toggle
False
Asserted 1
st
OFF
LOCAL
Toggle
True/False
Asserted 2
nd
LOCAL
OFF
Toggle
True
Asserted 2
nd
SYSTEM
OFF
Toggle
True/False
De-
asserted
ANY
NO CHANGE
Table 13 AVRA Functionality
