Personality Data Setup
Repeater Channel Setup Menu
Field Name
Options
/ Units
Description
Notes
Ch #
1-192
DVR Channel Number – referenced
in the Mobile Radio Channel Setup
when associating DVR channels to
Mobile Radio Modes.
Read Only Field.
Name
Seven (7)
character
string
DVR Channel name (alias)
displayed on the Control Head
when the DVR is enabled.
Channel Mode
F. Duplex
Simplex
Determines the DVR mode of
operation for the specific channel –
Full Duplex or Simplex.
Fire Ground
Yes / No
Enables or Disables Fireground
Signalling Capabilities on the
selected DVR channel.
Fireground (FG) signaling can be
enabled on analog or digital DVR
channels only.
Channel Type
Digital
Analog
Mixed
F.Analog
TPS
FA-All
Defines the DVR Channel Type.
Mixed Mode is selected when the
same DVR channel will be used by
Analog and P25 PSUs.
Rx Freq
[MHz]
DVR Rx Frequency (Must match
the PSU Tx Frequency).
Rx PL
[Hz] / DPL
DVR Rx PL / DPL (Must match the
Analog PSU Tx PL/DPL).
Applies to Analog, Mixed and F.
Analog Mode Only.
Tx Freq
[MHz]
DVR Tx Frequency (Must match the
PSU Rx Frequency).
Tx PL
[Hz] / DPL
DVR Tx PL / DPL (Must match the
Analog PSU Rx PL/DPL).
Applies to Analog, Mixed and F.
Analog Mode Only.
PL STE
[deg] /
DPL
Analog PSU PL/DPL Squelch Tail
Elimination – must be programmed
to match the PSU.
Applies to Analog, Mixed and F.
Analog Mode Only.
VR Mode
System
Local
User
Determines the Default DVR mode
when this DVR channel is selected.
TG Mode (Mobile Radio Channel
Setup) overwrites this setting.
Manual Mode
Change
Enabled
Disabled
Enables / Disables the DVR mode
change from the VRS button on the
Control Head. If this field is set to
Disabled, the VRS button still
toggles between the default DVR
mode and OFF mode.
This field is automatically set to
Enabled when the VR Mode is set
to User.
Tx Pwr
30-40
dBm
Specifies the selected Tx Output
Power at the DVR Antenna Port on
the DVR Tx frequency.
The Duplexer Tx Insertion Losses
as entered in the Interface to
Mobile Setup screen are
compensated by the DVR PA
Output to produce the
programmed Tx Power at the
Antenna Port.
