Futurecom P25 - Page 84

8M083X25 R14
APX Series P25 Interface
DVRS Installation & Programming Guide – PART II
January 2019
Page 84 of 153
Field Name
Range
Description
Notes
ANI 5 Tone Type
EEA
CCIR
EIA
Determines the ANI 5-Tone
Type.
Must match the Analog PSU
programming.
Affects Analog Mode only.
Emergency
Cancel
Analog Signaling
Type
Disable
ANI 5-Tones
DTMF
If enabled, the DVR will clear
the emergency upon detection
of the programmed Emergency
Cancel Code.
Affects Analog Mode only.
Emergency
Cancel
Timeout
OFF-1200sec
If programmed, the DVR will
automatically clear the
emergency upon expiration of
the programmed timer.
Affects all modes.
Emergency
Cancel
ANI Code
number
This field specifies the
Emergency Cancel ANI /DTMF
Code sequence. Must match
the Analog PSU programming.
Affects Analog Mode only.
Applicable only if the Emergency
Cancel Signaling Type Field is
Enabled.
The PSU must be programmed
with * as the last DTMF sign, for
example 456*.
FG Emergency
Destination
Local
System
Both
Determines the routing of
Emergency message received
by the DVR from a Local PSU
on a FG enabled DVR channel.
Applicable to DVR channels which
have FG signaling enabled.
Disable DVR
Emergency Call
State
Yes / No
When enabled, if emergency
alarm or call was declared by
an analog PSU, the DVR enters
Emergency Call State and
remains in this state until all the
MDC PSU emergencies are
cancelled by the PSU or DVR.
While in Emergency Call State
DVRS would forward all calls
received from the analog PSUs
without leading PTT ID as
emergency calls. Calls received
from analog PSUs with the
leading PTT ID would be
handled accordingly. The DVR
Emergency Call State is
cancelled by pressing the
DVRS button, by
preprogrammed emergency
cancel timer or remotely via
Emergency Cancel ANI code.
Applicable to Analog DVR mode
and analog PSUs only.
Use MSU
Emergency ID
Yes/No
When enabled the MSU ID is
used instead of the PSU ID to
proxy Emergency alerts.
Applicable to Analog DVR mode
and analog PSUs only.
Digital
Emergency
DVR Emergency
Echo ACK
Enabled
Enable /
Disable check
box
Must be Disabled when using
Generic P25 PSUs since they
will treat signaling level Ack as
application level Ack. Must be
Enabled when using DVRS
Enabled PSUs and ‘Console
Ack’.
Requires ‘Digital Emergency
Portable Ack Required’ to be
Enabled.
