CONFIGURE YOUR DEVICE
13 Customer Pole Display CD-220 VFD
4.2.1 Command Type
The CD-220 VFD supports up to 8 command sets. They are listed on the following
table. Please select one from the pull-down list.
Command Type Default
EPSON ESC/POS
*
DSP-800 (option)
ADM787/788 (option)
EMAX(AEDEX)
UTC/S
UTC/P
CD5220
Reserved
4.2.2 Language Character Set Selection
The CD-220 VFD supports the following language character set. Please refer to
following table for character code page.
Character Set(20h-7Fh) Code Table (80H-FFH) Default
U.S.A PC-437 (USA, Standard Europe) *
France
PC-858
Germany
U.K.
Denmark I
Sweden
Italy
Spain
Reserved
Norway PC-858
Denmark II
U.S.A Slavonic
U.S.A Russia
U.S.A PC-860 (Portuguese)
U.K. Greek
User Font
4.2.3 Baud Rate Selection
Baud Rate (bps) Default
9600 *
19200
38400
115200
