6.6 DSP-800 Mode Command Set (option)
Command Code (hex) Function Description
EOT SOH I n ETB
04 01 49 n 17
n=00~0Fh or 30~3Fh
Select International character set
(see Table 5-C)
EOT SOH P n ETB 04 01 50 n 17
31h≦n≦58h
Move cursor to specified position
EOT SOH C n m ETB 04 01 43 n m 17
31h≦n≦m≦58h
Clear display range from n to m
position and move cursor to n
position
EOT SOH S n ETB 04 01 53 n 17
31h≦n≦35h
Save the current view data to n layer
for demo display
EOT SOH D n m ETB 04 01 44 n m 17
31h≦n≦4Fh
31h≦m≦33h
Display the saved demo message
(see Table 5-D)
EOT SOH A n ETB 04 01 41 n 17
31h≦n≦34h
Brightness adjustment
EOT SOH F n ETB 04 01 46 n 17
00h≦n≦FFh
Blink display screen
n=00h for no blink
EOT SOH & n [px5]
ETB
04 01 26 n p1…p5 17
20h≦n≦FFh
1
51
5
Define download characters
EOT SOH ? n ETB 04 01 3F n 17
20h≦n≦FFh
Delete download characters
EOT SOH = n ETB 04 01 3D n 17
n=31h, 32h, 33h
Select peripheral device.
n=31h, select printer
n=32h, select display
n=33h, select printer + display
EOT SOH % ETB 04 01 25 17 Initialize display
EOT SOH @ ETB 04 01 40 17 Execute self-test
EOT SOH # n ETB 04 01 23 n 17 Command type select
n International Font
30h USA
31h France
32h German
y
33h UK
34h Denmark I
35h Sweden
36h Ital
y
37h S
p
ain
38h Ja
p
an
39h Norwa
y
3Ah Denmark II
Table 5-C International Font Set
n
Layer select
bit 0=1 La
y
er 1
bit 1=1 La
y
er 2
bit 2=1 La
y
er 3
bit 3=1 La
y
er 4
bit 4=0 La
y
er 5
m
Show mode
bit 0=1 Show mode 1
bit 1=1 Show mode 2
Table 5-D Layer table for saving data
