COMMAND SET
Customer Pole Display CD-220 VFD 20
US . n 1F 2E n
n=a displayable character
code
Specify period
US , n 1F 2C n
n=a displayable character
code
Specify comma
US ; n 1F 3B n
n=a displayable character
code
Specify semicolon
(period + comma)
ESC & s n m
[a(p1..pa)]x
m-n+1
1B 26 1 n m
[a(p1..pa)]x m-n+1
21h≦n≦m≦FFh; 1≦a≦5
p1..p5=row1...row5
Define download characters.
ESC ? n 1B 3F n
21h≦n≦FFh
Delete download characters.
ESC % n 1B 25 n
n=00h, 01h
Select/cancel download character set.
n=01 select, n=00 cancel
ESC W n s x1
y1 x2 y2
1B 57 n s x1 y1 x2 y2
1≦n≦4, s=00h,01h
01h≦x1≦x2≦14h
01h≦y1≦y2≦02h
Specify/cancel the window range.
s=01 specify, 00 cancel
n=select the window
x= column position
y= row position
ESC = n 1B 3D n
n=01h, 02h, 03h
Select peripheral device.
n=01h, select printer
n=02h, select display
n=03h, select printer + display
US : 1F 3A Set starting/ending position of macro
definition.
US ^ n m 1F 5E n m
00h≦n≦FFh
00h≦m≦FFh
Execute and quit macro.
n=word time
m=show string time
US T h m 1F 54 h m
00h≦h≦17h
00h≦m≦3bh
Display time
US U 1F 55 Display time continuously
US V n 1F 56 n
00h≦n≦01h
Status confirmation by DTR signal

