Computer module »DVI-CPU«
6 · Computer and console modules
Power supply
Power In: Plug the power cable of the power pack in this interface. Then connect the
power cable to the power pack and a power outlet.
Status displays
The LED on the back panel of the computer module shows the status of the external
power pack:
The blinking Transmission LEDs signal the following operating statuses:
LED Status Meaning
Power Green The external power pack is connected and the required voltage (12 Volt)
is available.
The LED to identify the device in the web application is deactivated.
Blue The external power pack is connected and the required voltage (12 Volt)
is available.
The LED to identify the device in the web application is activated.
Off The external power pack is not (properly) connected.
LED Colour Status Meaning
Left Yellow Off No console module accesses the computer module.
On A console module accesses the computer module.
Blinking The incoming video signal was not detected.
Flashing No voltage at PS/2 interface or USB bus.
Right Green Off The computer module is turned off.
On A console module accesses the computer module.
Blinking The connection to the counterpart could not be established.
Flashing The connection to the counterpart is established.
No console module is accessing.
Flickering Keyboard and mouse inputs are forwarded by the accessing
console module.
The flickering is defined by the user’s entries.
