Console module »DVI-CON-MC4«
114 · Computer and console modules
Startup
Turn on the console module after its installation.
Use the Main Power power pack or a redundant power pack to establish the power
supply:
Turn on the Main Power power pack.
Use an optional power pack to supply the Red. Power socket with power.
Automatic channel grouping
When operating the console module for the first time, the matrix switch recognises the
main channel and the console module’s additional channel. The channels are auto
-
matically added to a channel group.
The web application uses the following icons to mark the different types of channels:
Main channel: computer and user superimposed by the digit 2
Video channel: multiple monitors in a row
In the web application, the list of console modules lists grouped modules separately.
The
icon next to the module name shows that the module is part of a channel
group.
Click the icon to get information about the channel group.
NOTE:
In addition to the data of the KVM main channel, a channel group transmits
up to seven additional video channels and/or one USB 2.0 or RS
232 channel.
NOTE:
You can adjust any channel groups that were created automatically or
manually. More information about channel groups is given in the separate manu
-
als of the matrix switch web applications.
