Console module »DVI-CON-Fiber-MC4«
Computer and console modules · 153
TradeSwitch-LED
The optional TS-LED lights if the keyboard and mouse signals of a leader console
are accessing the console module.
Technical data
NOTE:
Keyboard and mouse signals can only access another console module or a
computer if you activated the TradeSwitch function for the matrix switch.
DVI-CON-FIBER-MC4
Interfaces to console Video: 4 × DVI-I (DVI Single-Link or VGA)
Keyboard and mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack plug
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
counterpart
Interface: 2 × LC-Duplex socket
Transmission distance: DVI-CPU-Fiber-MC4(M)
Max. 100 Meter (62,5μ/125μ),
Max. 200 Meter (50μ/125μ OM2)
Max. 400 Meter (50μ/125μ OM3)
DVI-CPU-Fiber-MC4(S)
Max. 5.000 Meter (9μ/125μ OS1)
DVI-CPU-Fiber-MC4(S+)
Max. 10.000 Meter (9μ/125μ OS1)
Video Max. resolutions: 1920 × 1200@60Hz
1280 × 1024@85Hz
Further VESA and CTA standardized
resolutions within the video
bandwidth and horizontal/vertical
frequency possible.
Colour depth: 24 Bit
Video bandwidth: 25 MHz to 165 MHz
Vertical frequency: 50 Hz to 180 Hz
Horizontal frequency: 30 kHz to 130 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Refresh rate: 96 kHz
Bandwidth: 22 kHz
