G&D DVI-CPU User Manual

Console module »DVI-CON-2-Fiber«
158 · Computer and console modules
Power supply
Main Power: Connect the power cable to the power pack and a power outlet.
Red. Power: If required, connect the power cable of the optional power pack to this
interface. This provides a redundant power supply. Connect the power cable with
the power pack and a power outlet of a different power circuit.
Start-up
Start the console module by pressing the Main Power button of the power pack.
Switching
The buttons on the front panel of the console module or configured key combinations
(select keys) let users switch between the connected matrix switches.
How to switch channels via buttons:
 Press the button of the desired channel to activate it.
How to switch channels via key combinations:
 On the console keyboard, press local Hotkey+Select key.
In the default settings, the select keys are Alt+1 (channel 1) and Alt+2 (channel 2).
ADVICE: The active hotkey configuration is displayed during the System Startup of
the matrix switch and the console module.
Main Power
LED Out
DVI/VGA OutTransmission 1
Transmission 2
Red. Power
Mouse
Keyb.Micro In
Speaker
Generic
Keyb./Mouse
LED
O
u
t
D
VI/V
G
A Ou
t
T
ransm
i
ss
i
on
1
Tr
a
n
s
mi
ss
ion
2
M
ou
s
e
K
e
yb.
Mi
cro
In
S
p
eake
r
G
eneri
c
K
e
yb
.
/M
ous
e
