Console module »DVI-CON-12V«
Computer and console modules · 167
Technical data
DVI-CON-12V
Interfaces to
console:
Video: 1 × DVI-I (DVI Single-Link or VGA)
Keyboard and mouse signals: 2 × PS/2 socket
2 × USB-A
Audio: 2 × 3.5 mm jack socket
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission
counterpart
Interface: 1 × RJ45 socket
Transmission length: Max. 140 meters
Video Max. resolutions: 1920 × 1200@60Hz
1280 × 1024@85Hz
Further VESA and CTA standardized
resolutions within the video
bandwidth and horizontal/vertical
frequency possible.
Colour depth: 24 bits
Pixel rate: 25 MHz to 165 MHz
Vertical frequency: 50 Hz to 180 Hz
Horizontal frequency: 30 kHz to 130 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Sampling rate: 96 kHz
Bandwidth: 22 kHz
Main power supply Type: External power pack
Connector: 4-pole Mini-DIN socket
Power input: 1.2A @ 12 VDC
Redundant
power supply
Type: External power pack
Connector: 4-pole Mini-DIN socket
Power input: 1.2A @ 12 VDC
