Configuration
Computer and console modules · 199
Changing the select keys
In the default settings, the select keys 1 and 2 are active to switch between the con-
nected computer modules.
You can also select another set of select keys.
How to select another set of select keys:
1. Press the Alt+Num (default) hotkey to open the OSD.
2. Select Hotkey and press Enter.
3. Select Selectkeys and press F8 to select one of the following options:
4. Press F2 to save your settings.
Administrating EDID profiles
The EDID information (Extended Display Identification Data) of a monitor gives the
graphics card of a connected computer information about various technical features
of the device.
The EDID profile of the monitor that is connected to the console module, is not
available at the computer module. Therefore, the computer module transmits a
standard profile to the computer. The EDID information of the profile are opti-
mised for the majority of available graphics cards.
NOTE:
Select keys can only be used and configured at console modules providing at
least two channels (e.
g. DVI-CON-2).
1, 2: Activates select keys 1 and 2
F1, F2: Activates select keys F1 and F2
NUM 1, NUM 2
Activates select keys NUM 1 and NUM 2
A , B: Activates select keys A and B
ADVICE:
In some cases it is recommended to send the EDID profile of the console
monitor to the computer module. Now the connected computer receives the EDID
data of the console monitor.
