Computer module »DVI-CPU-Fiber-UC«
32 · Computer and console modules
Connection to the matrix switch
Trans. 1|Tx: Insert the LC plug of a compatible optical fibre cable.
Connect the other end of the cable to the Rx interface of a Dynamic Port provided at
the first matrix switch.
Trans. 1|Rx: Insert the LC plug of a compatible optical fibre cable.
Connect the other end of the cable to the Tx interface of the same Dynamic Port
provided at the first matrix switch.
Trans. 2|Tx: Insert the LC plug of a compatible optical fibre cable.
Connect the other end of the cable to the Rx interface of a Dynamic Port provided
at the second matrix switch.
Trans. 2|Rx: Insert the LC plug of a compatible optical fibre cable.
Connect the other end of the cable to the Tx interface of the same Dynamic Port
provided at the second matrix switch.
Power supply
Power In: Connect the cable of the power pack to this interface. Now connect the
power cable to the power pack and a power socket.
The devices use components with laser technology which comply with laser
class
1.
They meet the requirements in accordance to EN 60825-1:2014 as well as
U.S. CFR 1040.10 and 1040.11.
Mind the following instructions when dealing with laser beams:
Avoid direct eye exposure to beam on page 3
Always connect optical connections or cover them with protection caps on page 3
Only use G&D certified transmission modules on page 3
NOTE:
Use optical fibres with LC plugs to connect the devices. The cables are avail-
able as accessories.
IMPORTANT:
For each matrix switch, connect only one Trans. interface of the
computer module!
ADVICE:
You can also connect the computer module directly to a compatible console
module.
