G&D DVI-CPU User Manual

Computer module »DVI-CPU-Fiber-UC«
Computer and console modules · 33
Status displays
The LED on the back panel of the computer module shows the status of the external
power pack:
The blinking LEDS on the back panel highlight the following operating statuses of
the particular connection:
LED Status Meaning
Power On The external power pack is connected and the required voltage (12 Volt)
is available.
Off The external power pack is not (properly) connected.
LED Colour Status Meaning
Left Yellow Off No console module accesses the computer module.
On A console module accesses the computer module.
Blinking The incoming video signal was not detected.
Flashing No voltage at PS/2 interface or USB bus.
Right Green Off The computer module is turned off.
On A console module accesses the computer module.
Blinking The connection to the counterpart could not be established.
Flashing The connection to the counterpart is established.
No console module is accessing.
Flickering Keyboard and mouse inputs are forwarded by the accessing
console module.
The flickering is defined by the user’s entries.

G&D DVI-CPU Specifications

General

Brand	G&D
Model	DVI-CPU
Category	Control Unit
Language	English
