Computer module »DL-DVI-CPU«
38 · Computer and console modules
Start-up
Connect the cable of the power pack to this interface. Now connect the power cable
to the power pack and a power socket.
Status displays
The Power LED on the back panel of the computer module shows the status of the
external power pack:
The flashing Transmission LEDs highlight the following operating statuses of the
particular connection:
LED Status Meaning
Power On The external power pack is connected and the required voltage (12 Volt)
is available.
Off The external power pack is not (properly) connected.
LED Colour Status Meaning
Left Yellow Off No console module accesses the computer module.
On A console module accesses the computer module.
Blinking The incoming video signal was not detected.
Flashing No voltage at PS/2 interface or USB bus.
Right Green Off The computer module is turned off.
On A console module accesses the computer module.
Blinking The connection to the counterpart could not be established.
Flashing The connection to the counterpart is established.
No console module is accessing.
Flickering Keyboard and mouse inputs are forwarded by the accessing
console module.
The flickering is defined by the user’s entries.
Yellow Flashing A firmware update is carried out.
