Gantner IDL 101 - Page 67

IDL 101
COMMUNICATION
HB_IDL101_E_V222.doc
65
Gantner Instruments Test & Measurement GmbH
Read the events
with # aa E cc <cr> > 1 b..b cc <cr>
> 0 e cc <cr>
NAK
without $ aa E <cr> = 1 b..b <cr>
= 0 e <cr>
NAK
Repeat reading the event
with # aa F cc <cr> > 1 b..b cc <cr>
> 0 e cc <cr>
NAK
without $ aa F <cr> = 1 b..b <cr>
= 0 e <cr>
NAK
write date and time
with # aa G t..t cc <cr> ACK NAK
without $ aa G t..t <cr> ACK NAK
Read date and time
with # aa H cc <cr> > t..t cc <cr> NAK
without $ aa H <cr> = t..t <cr> NAK
Read measuring rate and averaging interval
with # aa X cc <cr> > n..n cc <cr> NAK
without $ aa X <cr> = n..n <cr> NAK
Write measuring rate and averaging interval
with # aa Y n..n cc <cr> ACK NAK
without $ aa Y n..n <cr> ACK NAK
Reset pointer
with # aa C cc <cr> ACK NAK
without $ aa C <cr> ACK NAK
Set read pointer to index
with # aa C xxxxx cc <cr> ACK NAK
without $ aa C xxxxx <cr> ACK NAK
Set read pointer to date/time
with # aa C YYMMDDhhmmss cc <cr> ACK NAK
without $ aa C YYMMDDhhmmss <cr> ACK NAK
read number of events
with # aa N cc <cr> > a..a cc <cr> NAK
without $ aa N <cr> = a..a <cr> NAK
Transparent mode on (only at masterfunction)
with # aa T1 cc <cr> ACK NAK
without $ aa T1 <cr> ACK NAK
Transparent mode off (only at masterfunction)
with # aa T0 cc <cr> ACK NAK
without $ aa T= <cr> ACK NAK
Table 10.9 Instruction set in ASCII-protocol
