B. PINOUT ARRANGEMENTS FOR DIGITAL SENSORS
digital output
I/O 1 .... 16
0 V
status recording frequency measurement
I/O 1 .... 16
0 V
I/O 1 .... 16
0 V
f
progressive counter
I/O 1 .... 16
0 V
