Q.series

Gantner Instruments GmbH

4 Connecting the modules → Q.bloxx A116: Connecting sensors

4.18 Q.bloxx A116: Connecting sensors

The Q.bloxx Module A116 has eight analog inputs. We recom-

mend that either the Q.bloxx Connection Terminal A116 (Fig. 4-

71) or the Cable A116 (Fig. 4-72) is used with free ends for con-

nection. You will find the associated connector

s in each case at

the same place in the circuit diagrams, for example each of the

figures quoted in the second place belongs to one possible con-

nection method.

The channels (measurement ground) are electrically isolated

against the (modu

le) supply voltage and the interface.

Fig. 4-70 Pin assignment for Q.bloxx Module A116.

A1 –

A2 –

A3 U

Exc1+

A4 U

Exc1–

A5 U

Sen1–

A6 –

A7 U

Exc2+

A8 U

Exc2–

A9 U

Sen2–

A10 –

A11 U

Exc3+

A12 U

Exc3+

A13 U

Sen3–

A14 –

A15 U

Exc4+

A16 U

Exc4–

A17 U

Sen4–

A18 –

A19 U

Exc5+

A20 U

Exc5–

A21 U

Sen5–

A22 –

A23 U

Exc6+

A24 U

Exc6–

A25 U

Sen6–

A26 –

A27 U

Exc7+

A28 U

Exc7–

A29 U

Sen7–

A30 –

A31 U

Exc8+

A32 U

Exc8–

A33 U

Sen8–

A34 –

B1 B34

B3, B7, B11, B15, B19,

B23, B27, B31

(B5, B9, B13, B17,

B21, B25, B29, B33)

A3, A7, A11, A15, A19,

A23, A27, A31(+)

B4, B8, B12, B16, B20,

B24, B28, B32

A4, A8, A12, A16, A20,

A24, A28, A32 (–)

A5, A9, A13, A17, A21,

A3, A7, A11, A15, A19,

A23, A27, A31(+)

B1 –

B2 –

B3 U

Sig1+

B4 U

Sen1+

B5 U

Sig1–

B6 –

B7 U

Sig2+

B8 U

Sen2+

B9 U

Sig2–

B10 –

B11 U

Sig3+

B12 U

Sen3+

B13 U

Sig3–

B14 –

B15 U

Sig4+

B16 U

Sen14

B17 U

Sig4–

B18 –

B19 U

Sig5+

B20 U

Sen5+

B21 U

Sig5–

B22 –

B23 U

Sig6+

B24 U

Sen6+

B25 U

Sig6–

B26 –

B27 U

Sig7+

B28 U

Sen7+

B29 U

Sig7–

B30 –

B31 U

Sig8+

B32 U

Sen8+

B33 U

Sig8–

B34 –

A34A1

120 Ω

350 Ω

B3, B7, B11, B15, B19,

B23, B27, B31

A4, A8, A12, A16, A20,

A24, A28, A32 (–)

A3, A7, A11, A15, A19,

A23, A27, A31(+)

B3, B7, B11, B15, B19,

B23, B27, B31

A4, A8, A12, A16, A20,

A24, A28, A32 (–)
