Figure 4
Roller Housing Assembly – CU295900K
7
7
7
10
10
8
5
3
9
2
6
7
3
9
11
2
1
4
5
13
12
NOTE: Item 11 is a separate
assembly not included with the
roller housing (Figure 5).
Roller Housing Assembly-CU295900, cont.
Item # Part # # Req’d Description
9 CU300281 2 1
1
⁄4" Roller (Set of 2)
10 CU297104 2 Shaft, Roller
11 CK994900 1 Upper Roller Assm
(see Figure 5)
12 DC694104 1 Axle
13 CL343550 1 Grip, Handle
B2000-RK Kit includes:
Part#
Roller and Ring Kit
Qty
#4
1
1
⁄2" Roller
1
#5
2" Roller (Set of 2)
2
#8
1
1
⁄2" Roller
1
#9
1
1
⁄4" Roller (Set of 2)
2
#3
7
⁄8" External Retaining Ring
2
#7
7
⁄8" Carbon Spring Steel E-Clip
4
Roller Housing Assembly-CU295900K
Item # Part # # Req’d Description
1 CU296037K 1 Housing, Roller
2 CL61107 2 Bearing
3 Common Repl.
7
⁄8" External Retaining Ring
Part
4 CU299281 1 1
1
⁄2" Roller
5 CU298281 2 2” Roller (Set of 2)
6 CN452104K 1 Shaft, Roller
7 Common Repl. 4
7
⁄8" Carbon Spring Steel E-Clip
Part
8 CU319281 1 1
1
⁄2" Roller
*When the housing is ordered, the bearings will be pre-installed.
*
