23
Model B2000-8
(CURRENT)
B2000-7 B2000-6 B2000-5 B2000-4 B2000-3 B2000-2 B2000-1 B2000
(ORIGINAL)
Serial Number
Beginning With
N J
K
H F
G
E D C B A
Approximate
Manufacturing
Date
03/2014 07/2007 10/2004 03/2001 07/1997 05/1986 08/1984 01/1983 02/1982
HANDLE AND CONTROL CIRCUIT SUBASSEMBLY
4
GnD. Nut
B1018121 Interchangeable Interchangeable Interchangeable Interchangeable
(B1018121)
CJ458885 CJ458885 CJ458885 CJ458885
Screw (to fix CB)
CW401028 Interchangeable Interchangeable Interchangeable Interchangeable
(CW401028)
C991028 C991028 C991028 C991028
Pin
CM25061 Interchangeable Interchangeable Interchangeable Interchangeable
(CM25061)
N/A N/A N/A N/A
LEG AND WHEELS
5
Leg
LA205 Interchangeable Interchangeable
(LA205)
CL181900 CL181900 CL181900 CL181900 CL181900 N/A
Wheel
WB207 Interchangeable Interchangeable
(WB207)
CK456106 CK456106 CK456106 CK456106 CK456106 N/A
Caster
CB208 Interchangeable Interchangeable
(CB208)
BZK5106 N/A N/A N/A N/A N/A
Washer
N/A N/A N/A B1046108 B1046108 B1046108 B1046108 B1046108 N/A
Cotter Key
N/A N/A N/A B1011058 B1011058 B1011058 B1011058 B1011058 N/A
Rear Axle
N/A N/A N/A CU402950W CU402950W CU402950W CU402950W CU402950W N/A
1
Shoe Subassembly for model B2000-6 and newer has a different design from any previous models; many parts are not interchangeable.
2
Limit Switch Assembly for model B2000-8 has a different design from any previous model; many parts are not interchangeable.
3
Roller Housing Subassembly for model B2000-3 and newer has a different design from any previous models; many parts are not
interchangeable.
4
Handle and Control Circuit Assembly for model B2000-7 and newer has a different design from any previous models; many parts are
not interchangeable.
5
Leg and Wheels for model B2000-6 and newer has a different design from any previous models; many parts are not interchangeable.
GAR_TL_045_0717
800.822.9220 • Milwaukee, WI 53209 • gardnerbender.com
GARDNER BENDER LIMITED WARRANTY: Gardner Bender warrants its product against defects in workmanship and materials for 1 year from
date of delivery to user. Chain is not warranted. Warranty does not cover ordinary wear and tear, abuse, misuse, overloading, altered products or
use of improper fluid.
LIMITED: Limited means that GB warrants to the original purchasers of products from GB authorized distributors at the time of shipment such
products shall be free of defects in material and workmanship while the tool is used under normal working conditions. Standard wear and tear,
dulling over time, overloading, misuse, and acts of God are not covered under warranty. This warranty does not cover batteries, fuses,
or test leads.
When a warranty claim arises, the purchaser must contact GB. If the defect comes under the terms of this limited warranty,
GB will arrange, at its sole discretion, one of the following options:
• The product will be repaired at an authorized GB Service Center
• Product will be replaced
The purchaser is solely responsible for determining the suitability of GB for the purchaser’s use or resale, or for incorporating them into articles or
using them in the purchaser’s applications. The distributor is authorized to extend the foregoing limited warranty to its original purchasers in
connection with the sales of GB products, provided that such products shall not have been altered by the distributor. The distributor shall be fully
responsible for any warranties the distributor makes to its purchasers which are broader or more extensive than GB limited warranty.
LIFETIME WARRANTY
Warranty Limitation: The forgoing warranties are exclusive and are in lieu of all other express and implied warranties whatsoever, including but not
limited to implied warranties of merchantability and fitness for a particular purpose. The foregoing warranties do not cover ordinary wear and tear,
abuse, misuse, overloading, alterations, products which have not been installed, operated or maintained in accordance with GB written
instructions. Test leads, fuses, and batteries are not covered under any implied warranty. “Lifetime” of products that are no longer offered by GB
will be either repaired or replaced with an item of GB Instruments choice of similar value. Lifetime is defined as 5 years after GB discontinued
manufacturing the product, but the warranty period shall be at least ten years from date of purchase. Original proof of purchase is required to
establish original ownership of product.
No warranty will be honored unless an invoice or other proof of purchase date is provided to Gardner Bender.
Hand written receipts or invoices will not be honored.
