Garland MWG3W Service Manual

SERVICE MANUAL GARLAND CLAMSHELL GRILLS WITH PRODUCT RECOGNITION
PART #4526396 (03/30/10)Page 8
SK07-587 (GAS)
48°
5.475
[139mm]
9.684
[246mm]
36.027
[915mm]
1.146
[29mm]
22.835
[850mm]
4.895
[124mm]
4.064
[103mm]
"COLD ZONE"
34.968
[888mm]
1.516
[39mm]
1.598
[41mm]
24.084
[612mm]
.787
[20mm]
7.875 [200mm]
28.771
[731mm]
1.500
[38mm]
15.384
[391mm]
9.335
[237mm]
BOTTOM CABLE
ENTRANCE
13.123
[333mm]
BOTTOM CABLE
ENTRANCE
19.001
[483mm]
7.110
[181mm]
7.111
[181mm]
.737
[19mm]
24.000
[610mm]
(PLATE DEPTH)
36.000
[914mm]
(PLATE WIDTH)
30.714
[780mm]
30.750
[781mm]
TO
33.000
[838mm]
(COOKING
HEIGHT)
2.993
[76mm]
26.679
[678mm]
10.730
[273mm]
3/4" NPT GAS INLET
9.901
[251mm]
3/4" NPT GAS INLET
38.000
[965mm]
6.106
[155mm]
23.812
[605mm]
SPECIFICATIONS
Dimensions: Models MWE3W, MWG3W
[MWG3W ONLY]
[MWG3W ONLY]
FLUE EXIT
[MWG3W ONLY]
