Table6-6showswhichGFDSWeatherproductscanbedisplayed(indicatedwitha‘+’symbol)onspecic
G1000 maps.
GFDS Weather Product
PFD Inset Map
Navigation Map Page
Weather Data Link
(GFDS) Page
Weather Information
Page
AUX - Trip Planning
Page
AUX - Video Page
Nearest Page Group
Flight Plan Pages
Precipitation (PRECIP) + + + + + + +
Infrared Satellite (IR SAT) +
GFDS Data Link Lightning (DL LTNG) + + + + + + +
SIGMETs/AIRMETs (SIG/AIR) +
METARs + + + + + + + +
Winds Aloft (WIND) +
PIREPs + +
No Radar Coverage + + + +
TFRs + + + + + + +
TAFs + +
Table 6-6 GFDS Worldwide Weather Product Display Maps
SoftkeyscontrolthedisplayofweatherinformationonmostMFDpagesandthePFDInsetMap(Figure
6-57showstheweatherproductsoftkeysfortheWeatherDataLink(GFDS)Page).Whenaweatherproduct
isselectedfordisplay,thecorrespondingsoftkeylabelchangestograytoindicatetheproductdisplayis
enabled.

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
