ALTITUDE ALERTING

AltitudeAlertingprovidesthepilotwithavisualalertwhenapproachingtheSelectedAltitude.Wheneverthe

SelectedAltitudeischanged,theAltitudeAlerterisreset.TheAltitudeAlerterisindependentoftheGFC700

AFCS,butalertingtonesareheardonlywhentheGFC700isinstalled.Thefollowingoccurwhenapproaching

theSelectedAltitude:

•Uponpassingthrough1000feetoftheSelectedAltitudeanauraltoneisheard.TheSelectedAltitudechanges

toblacktextonalightbluebackgroundandashesfor5seconds.

•Whentheaircraftpasseswithin200feetoftheSelectedAltitude,theSelectedAltitudechangestolightblue

textonablackbackgroundandashesfor5seconds.

•AfterreachingtheSelectedAltitude,ifthepilotiesoutsidethedeviationband(±200feetoftheSelected

Altitude)anauraltoneisheard.TheSelectedAltitudechangestoyellowtextonablackbackgroundand

ashesfor5seconds.

Figure 2-34 Altitude Alerting Visual Annunciations

Within 1000 ft Within 200 ft Deviation of ±200 ft

LOW ALTITUDE ANNUNCIATION

NOTE: A Low Altitude Annunciation is available only when SBAS is available.

WhentheFinalApproachFix(FAF)istheactivewaypointinaGPSSBASapproachusingverticalguidance,

aLowAltitudeAnnunciationmayappearifthecurrentaircraftaltitudeisatleast164feetbelowtheprescribed

altitudeattheFAF.Ablack-on-yellowLOWALTannunciationappearstothetopleftoftheAltimeter,ashing

for several seconds, then remaining displayed until the condition is resolved.

Figure 2-35 Low Altitude on GPS SBAS Approach
