Garmin G1000 Diamond DA42NG User Manual

Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00962-02 Rev. A
72
FLIGHT INSTRUMENTS
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
MARKER BEACON ANNUNCIATIONS
MarkerBeaconAnnunciationsaredisplayedonthePFDtotheleftoftheSelectedAltitude.Outermarker
receptionisindicatedinblue,middleinyellow,andinnerinwhite.RefertotheAudioPanelandCNSSection
formoreinformationonMarkerBeaconAnnunciations.
Figure 2-32 Marker Beacon Annunciations
Inner Marker
Outer Marker
Altimeter
Middle Marker
TRAFFIC ANNUNCIATION
TrafcisdisplayedsymbolicallyonthePFDInsetMap,theMFDNavigationMapPage,andvariousother
MFD page maps.  Refer to the Hazard Avoidance Section and Appendix for more details about the Trafc
InformationService(TIS)andoptionalTrafcAdvisorySystems(TAS).Whenatrafcadvisory(TA)isdetected,
the following automatically occur:
•ThePFDInsetMapisenabledanddisplaystrafc.
•Aashingblack-on-yellowTRAFFICannunciationappearstothetopleftoftheAttitudeIndicatorforve
secondsandremainsdisplayeduntilnoTAsaredetectedinthearea.
•Asingle“TRAFFIC”auralalertisheard,unlessanoptionalTrafcAdvisorySystem(TAS)isinstalled.Refer
totheapplicableTASdocumentationforalertsgeneratedbyTASequipment.
IfadditionalTAsappear,newauralandvisualalertsaregenerated.
Traffic
Symbols
Figure 2-33 Traffic Annunciation and Inset Map with TAS Traffic Displayed

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
