Garmin G1000 Diamond DA42NG User Manual

190-00962-02 Rev. A
Garmin G1000 Pilot’s Guide for the Diamond DA42NG 421
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
InadditiontotheADS-Rservice,aGBTmayalsoprovidetheTrafcInformationService-Broadcast(TIS-B)
data,ifitisavailable.TIS-Breliesonsecondarysurveillanceradar(SSR)data,whichdetectsModeA,C,and
Stranspondertrafcwithintheradarservicearea.TheTIS-Bserviceisnotavailableinareaswithoutradar
surveillance,orwhentheaircraftisoutsideoftheradarservicearea.Thesystemmaydisplayradar-derived
TIS-BtrafcwithdegradedpositionalaccuracycomparedtoUATor1090EStrafc,whichself-reportGPS
positionsaboutonceasecond.TIS-Bdoesnotdetectaircraftwithoutoperatingtransponders.
GDL90trafcisintendedtobeusedbothin-ightandontheairportsurface.Systemsshouldbeenabled,
andremainenabled,wheneveroperatingintheairandontheairportsurface,unlessATCissuesarequesttostop
thetransmission.Thiscanbeaccomplishedbyselectingthetransponderstandbymode,whichalsodisables
theGDL90UATbroadcast.SeetheAudioPanelandCNSSectionformoreinformationabouttransponder
controls.
Thetrafcdisplaysarenot intended to be used as a collision avoidance system and the system not relieve
thepilot’sresponsibilityto“seeandavoid”otheraircraft.Thetrafcdisplaysmustnotbeusedforavoidance
maneuversduringIMCorothertimeswhenthereisnovisualcontactwiththeintruderaircraft.TheADS-B
systemisintendedonlytoassistinvisualacquisitionofotheraircraft.Itdoesnotprovideavoidancemaneuvers.
TRAFFIC DESCRIPTION
UATtrafcoperationissimilartotheTASsystemdiscussedpreviouslyinsection6.10,withtheexception
ofsymbology.Thesystemdisplaysthetrafcusingthesymbolsshowninthetablebelow.Aboveorbelow
thetrafcsymbolisthetrafcidentier,andaltitude(ifavailable).Asmallupordownarrownexttothetrafc
symbolindicatesthatthetrafcisclimbingordescendingatarateofatleast500feetperminute.Thevector
linethatextendsbeyondthepointofthetrafcarrowisjustfurtherindicationoftheintruderaircrafttrack,
if directional information is available.

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
