Garmin G2000 Cockpit Reference Guide for the Cessna Corvalis T240
190-01264-01 Rev. A
82
Hazard Avoidance
Flight
InstrumentsEIS
Nav/Com/
XPDR/AudioAFCSFMS Nav
Flight
PlanningProcedures
Hazard
Avoidance
Additional
Features
Abnormal
Operation
Annun/
AlertsAppendixIndex
TERRAIN-SVT
NOTE: Terrain-SVT is only available when the Synthetic Vision Technology
(SVT) option is installed and the TAWS option has not been installed.
NOTE: Terrain data is not displayed when the aircraft is outside of the installed
terrain database coverage area.
Displaying Terrain-SVT on the Terrain-SVT Display:
From the Home Screen, touch Terrain SVT.
Color Terrain/Obstacle Location
Red
Terrain/Obstacle above or within 100’
below current aircraft altitude.
Yellow
Terrain/Obstacle between 100’ and
1000’ below current aircraft altitude.
Black
Terrain/Obstacle is more than 1000’
below aircraft altitude.
Enabling/disabling terrain information on the Navigation Map Display:
1)
From the Home Screen, touch Map > Map Settings.
2)
Touch the Terrain Data Button to display/remove terrain data on the
navigation map. When the annunciator on the button is green, the system
displays terrain data. When the annunciator is gray, the system removes
terrain data from the navigation map.
Or:
1)
From the Home Screen, touch Map > Map Settings > Map Options.
2)
If necessary, touch the Map Tab.
3)
Scroll to find the Terrain Data Button.
4)
Touch the Terrain Data Button to enable/disable terrain data.
To Next Page
