GPSMAP 9x2/9x2 Plus Specifications
Dimensions (W × H × D) 25.6 × 16.2 × 5.2 cm (10.1 × 6.4 ×
2.1 in.)
Display size (W × H) 19.6 × 11.4 cm (7.7 × 4.5 in.)
9 in. diagonal
Display resolution WSVGA, 1024 × 600 pixels
Weight 9x2: 1.14 kg (2.5 lb.)
9x2 Plus: 1.27 kg (2.8 lb.)
Compass-safe distance 76 cm (30 in.)
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast
aluminum
Water rating IEC 60529 IPX7
1
Fuse 6 A, 125 V fast-acting
Input voltage From 10 to 32 Vdc
Max. power usage at 10 Vdc 27 W
Typical current draw at 12 Vdc 1.3 A
Max. current draw at 12 Vdc 2.3 A
NMEA 2000 LEN @ 9 Vdc 2
NMEA 2000 draw 75 mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Wireless frequency 2.4 GHz @ 17.6 dBm nominal
Memory card 2 SD card slots; 32 GB max. card size
HTML integration Compatible with OneHelm integration
(Plus models only)
GPSMAP 12x2 Touch/A12/12x2 Plus Specifications
Dimensions (W × H × D) 33.0 × 22.6 × 7.9 cm (13.0 × 8.9 ×
3.1 in.)
Display size (W × H) 26.2 × 16.3 cm (10.3 × 6.4 in.)
12 in. diagonal
Display resolution WXGA, 1280 × 800 pixels
Weight 2.72 kg (6.0 lb.)
Compass-safe distance 65 cm (25.6 in.)
Clearance to nearest
obstruction
9.5 cm (3
3
/
4
in.)
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast
aluminum
Water rating IEC 60529 IPX7
1
Fuse 6 A, 125 V fast-acting
Input voltage From 10 to 32 Vdc
Max. power usage at 10 Vdc 36 W
Typical current draw at 12 Vdc 2.5 A
Max. current draw at 12 Vdc 3.0 A
NMEA 2000 LEN @ 9 Vdc 2
NMEA 2000 Draw 75 mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Memory card 2 SD card slots; 32 GB max. card size
Wireless frequency 2.4 GHz @ 19.5 dBm nominal
HTML integration Compatible with OneHelm integration
(Plus models only)
1
The device withstands incidental exposure to water of up to 1 m for up to 30 min.
For more information, go to www.garmin.com/waterrating.
GPSMAP 7x3 Specifications
Dimensions (W × H × D) 192.3 × 140.3 × 74.1 mm (7
9
/
16
× 5
1
/
2
× 2
15
/
16
in.)
Clearance to next obstruction 27.8 mm (2 in.)
Display size (W × H) 154.6 × 91.0 mm (6
1
/
16
× 3
9
/
16
in.)
17.8 cm (7.0 in.) diagonal
Display resolution WSVGA, 1024 × 600 pixels
Weight 1.3 kg (2.8 lb.)
Compass-safe distance 35 cm (13.78 in.)
Max. power usage at 10 Vdc Non-sonar models: 17.6 W
Sonar models: 35.9 W
Typical current draw at
12 Vdc
Non-sonar models: 1.08 A
Sonar models: 1.18 A
Max. current draw at 12 Vdc Non-sonar models: 1.45 A
Sonar models: 2.96 A
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast
aluminum
Water rating IEC 60529 IPX7
1
Input voltage From 10 to 32 Vdc
Fuse 6 A, 125 V fast-acting
NMEA 2000 LEN @ 9 Vdc 2
NMEA 2000 draw 75 mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Wireless frequency 2.4 GHz @ 17.6 dBm nominal
Memory card 2 microSD card slots; 32 GB max. card
size
GPSMAP 9x3 Specifications
Dimensions (W × H × D) 233.0 × 162.3 × 75.8 mm (9
3
/
16
× 6
3
/
8
× 3 in.)
Clearance to next obstruction 33.2 mm (1
5
/
8
in.)
Display size (W × H) 198.7 × 111.8 mm (7
13
/
16
× 4
3
/
8
in.)
22.9 cm (9.0 in.) diagonal
Display resolution WXGA, 1280 ×720 pixels
Weight 1.6 kg (3.6 lb.)
Compass-safe distance 30 cm (11.81 in.)
Max. power usage at 10 Vdc Non-sonar models: 22.0 W
Sonar models: 40.2 W
Typical current draw at
12 Vdc
Non-sonar models: 1.34 A
Sonar models: 1.37 A
Max. current draw at 12 Vdc Non-sonar models: 1.78 A
Sonar models: 3.20 A
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast
aluminum
Water rating IEC 60529 IPX7
1
Input voltage From 10 to 32 Vdc
Fuse 6 A, 125 V fast-acting
NMEA 2000 LEN @ 9 Vdc 2
NMEA 2000 draw 75 mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Wireless frequency 2.4 GHz @ 17.6 dBm nominal
Memory card 2 microSD card slots; 32 GB max. card
size
1
The device withstands incidental exposure to water of up to 1 m for up to 30 min.
For more information, go to www.garmin.com/waterrating.
