Gatekeeper Systems 304-SD - Osd Overlay; Table 7: Osd Overlay Options

- 31 -
Options 2.
METADATA CAPTURE
Reserved for future development
RECORD FILE TIME (MIN)
Sets the length in minutes of the recorded video file
HDD / SD OVRWRITE
Options: ON / OFF
ON:
When the SD Card has less than 2G, the 304-SD will begin to
delete the oldest recorded files until the SD card available space is
equal to, or over 10GB. Alarm files will remain as they are in a
locked state.
OFF:
304-SD will stop recording when SD Card is full, (less than
500MB). You must replace the SD Card or delete files manually for
the 304-SD to begin recording again.
Default: ON
LOCKED FILE RETENTION(DAY)
Options: 7, 10, 15, 20, 30, 45 days.
Determines the length of time, in days, which a recorded file triggered by an
alarm will be “Locked”, Read-Only. Once the specified amount of time has
elapsed the file can be deleted.
Default: 15
PRE-RECORDING SWITCH
Reserved for future development
SD CARD TYPE
Reserved for future development
MIRROR REC. TO SD CARD
Reserved for future development
OSD OVERLAY
The OSD Overlay options controls what will be displayed on the On Screen Display and Recorded Video. The value can
either be ON or OFF, except for position which has a TOP or BOTTOM option.
LIVEVIEW controls what will be visible when the output of the 304-SD is viewed either via the ICD accessory, or, the
RCA output connection on the front of the Digital Video Recorder.
If IMAGE is set to ON then the recorded video will display this information as part of the playback when viewed via G4
Viewer.
ITEMS
LIVEVIEW
POSITION
DATE/TIME
ON/OFF
ON/OFF
TOP/BOTTOM
ALARM
ON/OFF
ACCEL. DATA
ON/OFF
TEMPERATURE
ON/OFF
FIRMWARE VERSION
ON/OFF
GPS INFO
ON/OFF
CH NAME
ON/OFF
VEHICLE NO.
ON/OFF
ON/OFF
SPEED
ON/OFF
ON/OFF
Table 7: OSD Overlay Options
