CartManager XD Field Technician Guide Page 6
DESCRIPTION OF THE FUNCTION
It is a connection block where power is distributed.
Brake relay ( XDW, XD, XD+)
Turns the brake light off when the CartManager is moving.
Turns the unlock signal on and off when the machine is moving and
stopped respectively. This is for use with shopping carts that have a
Gatekeeper Systems’ wheel.
Puts the CartManager in slow speed mode when the battery is low to
avoid damage to the batteries.
First talks to the remote to be connected and then receives signal from
the remote, to place output signals to the speed board or horn. It also
send the (unlock) signal out through the antenna for the shopping carts.
Outputs resistance for the throttle control.
Warning beacon to allow the CartManager to be seen at night.
When engaged it stops the unit from moving.
Switches on the CartManager, initiates power to the rest of the machine.
